SiC Schottky

Download

Consult

Application

No Data

Product Features

Application

Parameter

Product Name	Package	Blocking Voltage(V)	Current Rating(A)	Generation	Forward Voltage VF（V）	Reverse leakage current IR（uA）	Forward surge current IFSM(A)	Total Capacitive Charge QC(nC)	Total Power Dissipation PTOT(W)	Thermal resistance RthJ-C(°C/W)
YJD106502DQG3	TO-252	650	2	Gen3	1.5	0.1	20	5.2	42	3.62
YJD106502PQG3	TO-220AC	650	2	Gen3	1.5	0.1	20	5.2	45	3.33
YJD106504DG1	TO-252	650	4	Gen1	1.4	3	26	12	59	2.52
YJD106504PG1	TO-220AC	650	4	Gen1	1.4	3	26	12	56	2.65
YJD106506BQG2	TO-263/D2PAK	650	6	Gen2	1.31	0.5	65	25	84	1.75
YJD106506DQG2	TO-252/DPAK	650	6	Gen2	1.31	0.5	65	25	100	1.49
YJD106506FQG2	ITO-220AC	650	6	Gen2	1.31	0.5	65	25	31	4.76
YJD106506PQG2	TO-220AC	650	6	Gen2	1.31	0.5	65	25	84	1.78
YJD106508BQG2	TO-263/D2PAK	650	8	Gen2	1.3	0.5	70	30	136	1.1
YJD106508DQG2	TO-252/DPAK	650	8	Gen2	1.3	0.5	70	30	132	1.14
YJD106508FQG2	ITO-220AC	650	8	Gen2	1.3	0.5	70	30	43	3.5
YJD106508PQG2	TO-220AC	650	8	Gen2	1.3	0.5	70	30	136	1.1
YJD106510BQG2	TO-263	650	10	Gen2	1.35	0.5	80	30	136	1.1
YJD106510DQG2	TO-252	650	10	Gen2	1.35	0.5	80	30	136	1.1
YJD106510FQG2	ITO-220AC	650	10	Gen2	1.35	0.5	80	30	43	3.5
YJD106510NQG2	TO-247AC	650	10	Gen2	1.35	0.5	70	30	126	1.19
YJD106510PQG2	TO-220AC	650	10	Gen2	1.35	0.5	80	30	136	1.1
YJD106520BQG2	TO-263	650	20	Gen2	1.35	1	160	62	144	1.04
YJD106520BQG3	TO-263	650	20	Gen3	1.2	2	380	135.3	375	0.4
YJD106520DQG2	TO-252	650	20	Gen2	1.35	1	160	62	150	1
YJD106520FQG2	ITO-220AC	650	20	Gen2	1.35	1	160	62	47	3.2
YJD106520NCTQG2	TO-247AB	650	20	Gen2	1.35	0.5	80*	30*	230	0.65
YJD106520NCTQG3	TO-247AB	650	20	Gen3	1.55	0.5	70	25	84/166	1.78/0.9
YJD106520NQG2	TO-247AC	650	20	Gen2	1.35	1	160	62	187	0.8
YJD106520PQG2	TO-220AC	650	20	Gen2	1.35	1	160	62	170	0.88
YJD106540NCTQG2	TO-247AB	650	40	Gen2	1.35	1	160*	62*	365	0.41
YJD106550BQG3	TO-263	650	50	Gen3	1.45	3	380	135.3	375	0.4
YJD106550NQG3	TO-247AC	650	50	Gen3	1.45	3	380	135.3	454	0.33
YJD112002DG1	TO-252/DPAK	1200	2	Gen1	1.41	3	25	14	46	3.3
YJD112002PG1	TO-220AC	1200	2	Gen1	1.41	3	25	14	47	3.2
YJD112005DG1	TO-252/DPAK	1200	5	Gen1	1.4	1.8	52	37	57	2.6
YJD112005DGH	TO-252	1200	5	GH	1.4	0.5	50	27	88	1.7
YJD112005FG1	ITO-220AC	1200	5	Gen1	1.4	1.8	52	37	31	4.8
YJD112005FGH	ITO-220AC	1200	5	GH	1.4	0.5	50	27	33	4.5
YJD112005PG1	TO-220AC	1200	5	Gen1	1.4	1.8	52	37	79	1.9
YJD112010BQG2	TO-263	1200	10	Gen2	1.42	1.3	85	53	158	0.95
YJD112010BXQG2	TO-263	1200	10	Gen2	1.42	1.3	85	53	158	0.95
YJD112010DQG2	TO-252	1200	10	Gen2	1.42	1.3	85	53	189	0.79
YJD112010FQG2	ITO-220	1200	10	Gen2	1.42	1.3	85	53	36	4.1
YJD112010NQG2	TO-247AC	1200	10	Gen2	1.42	1.3	85	53	266	0.56
YJD112010PQG2	TO-220	1200	10	Gen2	1.42	1.3	85	53	170	0.88
YJD112015NGG2	TO-247AC	1200	15	Gen2	1.25	0.5	144	114	319	0.47
YJD112015PGG2	TO-220AC	1200	15	Gen2	1.25	0.5	140	114	241	0.62
YJD112020BXGG2	TO-263	1200	20	Gen2	1.34	0.5	160	114	214	0.7
YJD112020NCTQG2	TO-247AB	1200	20	Gen2	1.42	1.3	85*	53*	500	0.30
YJD112020NGG2	TO-247AC	1200	20	Gen2	1.34	0.5	160	114	319	0.47
YJD112020PGG2	TO-220AC	1200	20	Gen2	1.34	0.5	160	114	241	0.62
YJD112030NCTGG2	TO-247AB	1200	30	Gen2	1.24	0.5	140*	110	588	0.25
YJD112030NG1	TO-247AC	1200	30	Gen1	1.54	1	240	153	394	0.38
YJD112030NGG3	TO-247AC	1200	30	Gen3	1.54	0.5	250	122	326	0.46
YJD112030NQG2	TO-247AC	1200	30	Gen2	1.43	3.4	225	162	416	0.36
YJD112040NCTGG2	TO-247AB	1200	40	Gen2	1.34	0.5	160*	228	638	0.24
YJD112040NGG2	TO-247AC	1200	40	Gen2	1.38	1	300	222	573	0.26
YJD112040NQG2	TO-247AC	1200	40	Gen2	1.41	3.1	280	216	440	0.34
YJD112060NQG2	TO-247AC	1200	60	Gen2	1.45	2	445	320	750	0.2
YJD117020NCTG1	TO-247AB	1700	20	Gen1	1.4	1.8	64*	170	234/468	0.64/0.32
